Vienna rectifier

This section describes vienna rectifier

A block diagram and input parameters for a Vienna rectifier are given in Table 1.

Table 1. A Vienna rectifier component in the Schematic Editor core library
component component dialog window component parameters

Vienna rectifier

  • Control (Digital inputs, Model)
  • Phase A S1 (1..32)
  • Phase B S1 (1..32)
  • Phase C S1 (1..32)
  • gate_logic (active high, active low)
  • _control_property (all high, all low)
  • Gate control enabling (enables usage of external digital signal to enable the switching)
  • Sen (digital input selection for PWM enable)
  • Sen_logic (active high, active low)
Weight = 3

A schematic block diagram of the inverter switching block is given in Figure 1 with corresponding switch arrangement and naming.

Figure 1. A schematic block diagram of a Vienna rectifier block with corresponding switch naming

Digital inputs, when selected for Control parameter, enables the user to assign gate drive inputs to any of the digital input pins (from 1 to 32). For example, if Phase A S1 is assigned to 1, the digital input pin 1 will be routed to the Phase A S1 switch gate drive. In addition, the gate_logic parameter selects either active high (High-level input voltage VIH turns on the switch), or active low (Low-level input voltage VIL turns on the switch) gate drive logic, depending on the user’s external controller design.

Model, when selected for Control parameter, enables the user to set the IGBTs gate drive signals directly from signal processing model. The input pin gates appears on the component and requires a vector input of three gate drive signals in the following order: [Phase A S1, Phase B S1, Phase C S1]. When controlled from the model, logic is always active high.

Digital Alias

If a converter is controlled by digital inputs, an alias for every digital input used by the converter will be created. Digital input aliases will be available under the Digital inputs list alongside existing Digital input signals. The alias will be shown as Converter_name.Switch_name, where Converter_name is name of the converter component and Switch_name is name of the controllable switch in the converter.
