Toolbox Offerings
Typhoon HIL Control Center (THCC) comes with a wide variety of pre-built components that can be further enriched your project builds quickly through our selected toolbox package offerings.
Explore toolbox packages tailored to your needs.
Our toolbox packages range from our basic, free option to our flagship premium, paid subscription – providing features, functionalities, and modules that extend the capabilities of the core Typhoon HIL hardware and software. Not sure what package is right for you? Browse the component library explorer and contact us to request a free trial to help you decide.
| Toolboxes | Basic | Communication | Expert Power Electronics | Microgrid | Premium |
|---|---|---|---|---|---|
| Basic Schematic Editor Libraries | ✓ | ✓ | |||
| Virtual HIL | ✓ | ✓ | |||
| Modbus Protocol | ✓ | ✓ | |||
| IEC61850 Protocols | ✓ | ✓ | |||
| C37.118 Protocol | ✓ | ✓ | |||
| Ethernet Variable Exchange | ✓ | ✓ | |||
| SFP Simulation Link | ✓ | ✓ | |||
| CAN bus | ✓ | ✓ | |||
| DNP3 Protocol | ✓ | ✓ | |||
| EtherCAT Protocol | ✓ | ✓ | |||
| PROFINET Protocol | ✓ | ✓ | |||
| IEC 60870 Protocol Toolbox | ✓ | ✓ | |||
| ISO 15118 Protocol | ✓ | ||||
| Power Loss Calculation | ✓ | ✓ | |||
| Nonlinear Machines | ✓ | ✓ | |||
| TyphoonTest | ✓ | ✓ | |||
| Microgrid | ✓ | ✓ | |||
| Power Systems | ✓ | ✓ |
How to use Signal Processing Toolbox
Find out how easy it is to integrate signal processing with the power stage modeling, and how quickly you can create control prototypes that run on high-fidelity, real-time HIL simulators.
