Termination

Description of the Termination component in Schematic Editor, which terminates a floating signal.

Component Icon

Figure 1. Termination icon

Description

The Termination component is used for terminating a signal that is floating on the schematic editor.

Ports

  • In (in)
    • Signal to be terminated.
      • Supported types: uint, int, real.
      • Vector support: yes.

Properties

  • Execution rate
    • Type in the desired signal processing execution rate. This value must be compatible with other signal processing components of the same circuit: the value must be a multiple of the fastest execution rate in the circuit. There can be up to four different execution rates, but they must all be multiple of the basic simulation timestep. To specify the execution rate, you can use either decimal (e.g. 0.001) or exponential values (e.g. 1e-3) in seconds. Alternatively, you can type in ‘inherit’ in which case the component will be assigned execution rate based on the execution rate of the components it is receiving input from.
